Jentchina

API

libJentchina.h

/*
 * libJentchina.h
 * Part of the Birds Lake project
 * STRASSER Michel <michelNOSPAM.strasserNOSPAM@freeNOSPAM.frNOSPAM>
 * 20040414_0945        Initial Release
 * */

#ifndef __LIB_JENTCHINA_H__
#define __LIB_JENTCHINA_H__

#include <Jentchina/JentchinaObj.h>
#include <Jentchina/JentchinaTreeModel.h>

#endif

JentchinaObj.h

/* Jentchina - Obj
 * STRASSER Michel - 20040406           init
 * */

#ifndef __JENTCHINA_OBJ_H__
#define __JENTCHINA_OBJ_H__

#include <glib.h>
#include <glib-object.h>
#include <lsmlib.h>

#define JENTCHINA_TYPE_OBJ                      (JentchinaObj_getType ())
#define JENTCHINA_OBJ(object)           (G_TYPE_CHECK_INSTANCE_CAST ((object), JENTCHINA_TYPE_OBJ, JentchinaObj))
#define JENTCHINA_OBJ_CLASS(object)             (G_TYPE_CHECK_CLASS_CAST ((object), JENTCHINA_TYPE_OBJ, JentchinaObjClass))
#define JENTCHINA_IS_OBJ(object)                (G_TYPE_CHECK_INSTANCE_TYPE((object), \
                                                        JENTCHINA_TYPE_OBJ))
#define JENTCHINA_IS_OBJ_CLASS(klass)   (G_TYPE_CHECK_CLASS_TYPE((klass), \
                                                        JENTCHINA_TYPE_OBJ))
#define JENTCHINA_OBJ_TYPE(object)                (G_TYPE_FROM_INSTANCE (object))
#define JENTCHINA_OBJ_TYPE_NAME(object)   (g_type_name (JENTCHINA_OBJ_TYPE (object)))

typedef struct _JentchinaObj    JentchinaObj;
typedef struct _JentchinaObjClass       JentchinaObjClass;

#ifndef JENTCHINA_ITER
#define JENTCHINA_ITER
typedef guint32 JentchinaIter;
#endif

typedef enum {
        JentchinaFilterType_IMPORT,
        JentchinaFilterType_EXPORT,
        JentchinaFilterType_NUM
} JentchinaFilterType;

typedef enum {
        JentchinaTreeModelType_SERVER,
        /* JentchinaTreeModelType_CATEGORY, TODO later */
        JentchinaTreeModelType_NUM
} JentchinaTreeModelType;

typedef enum {
        /* TODO */
        JentchinaStatus_OK,
        JentchinaStatus_BAD_OBJ,
        JentchinaStatus_INVALID_ITER,
        JentchinaStatus_INVALID_SESSION_KEY,
        JentchinaStatus_APPLY_FILTER_ERROR,
        JentchinaStatus_SYSTEM_ERROR, /* may be network error */
        JentchinaStatus_NUM
} JentchinaStatus;


struct _JentchinaObj
{
        GObject                 parent_instance;

        /* private */
        GObject*                cnl;            /* JnaCnlJentchina */
};

struct _JentchinaObjClass
{
        GObjectClass            parent_class;
};

G_BEGIN_DECLS

GType
JentchinaObj_getType            (void);

GObject*
JentchinaObj_new                                (char* appName);

GObject*        /* JentchinaTreeModel */
JentchinaObj_getNewModel                        (JentchinaObj* self,
                                                 JentchinaFilterType filterType,
                                                 JentchinaTreeModelType modelType);

JentchinaStatus
JentchinaObj_getRendezVous                      (JentchinaObj* self,
                                                 JentchinaIter in_iter,
                                                 char* in_user,
                                                 char* in_password,
                                                 LsmTree* in_doc,
                                                 GList** out_interfaces,        /* newly allocated, list of string */
                                                 int* out_vortexLifeTime,       /* not supported yet */
                                                 char** out_sessionKey);        /* newly allocated */

JentchinaStatus
JentchinaObj_applyFilter                        (JentchinaObj* self,
                                                 char* in_sessionKey,
                                                 char* in_interfacesStream,
                                                 LsmTree** out_filteredDoc);    /* newly allocated */

JentchinaStatus
JentchinaObj_getInfos                           (JentchinaObj* self,
                                                 JentchinaIter in_iter,
                                                 char** out_serverName,         /* newly allocated */
                                                 char** out_serverPic,          /* newly allocated */
                                                 char** out_filterName,         /* newly allocated */
                                                 int* out_version,
                                                 char** out_year,               /* newly allocated */
                                                 char** out_license,            /* newly allocated */
                                                 char** out_application,        /* newly allocated */
                                                 char** out_info,               /* newly allocated */
                                                 GList** out_authors,           /* newly allocated, list of string */
                                                 char** out_filterPic);         /* newly allocated */




JentchinaStatus
JentchinaObj_getAuthorInfos                     (JentchinaObj* self,
                                                 JentchinaIter iter,
                                                 char* in_id,
                                                 char** out_name,               /* newly allocated */
                                                 char** out_email,              /* newly allocated */
                                                 char** out_picture);           /* newly allocated */

void
JentchinaObj_setData                            (JentchinaObj* self,
                                                 JentchinaIter iter,
                                                 int data);                     /* you may cast your data with GPOINTER_TO_INT */

int     /* you may cast your data with INT_TO_GPOINTER */
JentchinaObj_getData                            (JentchinaObj* self,
                                                 JentchinaIter iter);

/* for debugging purposes only, prints a Java's toString() alike string of the actual state, this may be very verbose */
void
JentchinaObj_print                              (JentchinaObj* self);

G_END_DECLS

#endif /* __JENTCHINA_OBJ_H__ */

JentchinaTreeModel.h

/* Jentchina - TreeModel
 * STRASSER Michel - 20040405           init
 * */

#ifndef __JENTCHINA_TREE_MODEL_H__
#define __JENTCHINA_TREE_MODEL_H__

#include <glib.h>
#include <glib-object.h>

#define JENTCHINA_TYPE_TREE_MODEL                       (JentchinaTreeModel_getType ())
#define JENTCHINA_TREE_MODEL(object)            (G_TYPE_CHECK_INSTANCE_CAST ((object), JENTCHINA_TYPE_TREE_MODEL, JentchinaTreeModel))
#define JENTCHINA_TREE_MODEL_CLASS(object)              (G_TYPE_CHECK_CLASS_CAST ((object), JENTCHINA_TYPE_TREE_MODEL, JentchinaTreeModelClass))
#define JENTCHINA_IS_TREE_MODEL(object)         (G_TYPE_CHECK_INSTANCE_TYPE((object), \
                                                        JENTCHINA_TYPE_TREE_MODEL))
#define JENTCHINA_IS_TREE_MODEL_CLASS(klass)    (G_TYPE_CHECK_CLASS_TYPE((klass), \
                                                        JENTCHINA_TYPE_TREE_MODEL))
#define JENTCHINA_TREE_MODEL_TYPE(object)                 (G_TYPE_FROM_INSTANCE (object))
#define JENTCHINA_TREE_MODEL_TYPE_NAME(object)    (g_type_name (JENTCHINA_TREE_MODEL_TYPE (object)))

typedef struct _JentchinaTreeModel      JentchinaTreeModel;
typedef struct _JentchinaTreeModelClass JentchinaTreeModelClass;

#ifndef JENTCHINA_ITER
#define JENTCHINA_ITER
typedef guint32 JentchinaIter;
#endif

struct _JentchinaTreeModel
{
        GObject                 parent_instance;
};

struct _JentchinaTreeModelClass
{
        GObjectClass            parent_class;

        gint            (*getNColumns)                  (JentchinaTreeModel* self);

        GType           (*getColumnType)                (JentchinaTreeModel* self,
                                                         gint index);


        gboolean        (*getIter)                      (JentchinaTreeModel* self,
                                                         JentchinaIter* out_iter,
                                                         char* path);

        char*           (*getPath)                      (JentchinaTreeModel* self,
                                                         JentchinaIter iter);

        void            (*getValue)                     (JentchinaTreeModel* self,
                                                         JentchinaIter iter,
                                                         gint column,
                                                         GValue* out_value);

        gboolean        (*iterNext)                     (JentchinaTreeModel* self,
                                                         JentchinaIter* inOut_iter);

        gboolean        (*iterChildren)                 (JentchinaTreeModel* self,
                                                         JentchinaIter* out_iter,
                                                         JentchinaIter parent);

        gboolean        (*iterHasChild)                 (JentchinaTreeModel* self,
                                                         JentchinaIter iter);

        gint            (*iterNChildren)                (JentchinaTreeModel* self,
                                                         JentchinaIter iter);

        gboolean        (*iterNthChild)                 (JentchinaTreeModel* self,
                                                         JentchinaIter* out_iter,
                                                         JentchinaIter parent,
                                                         int n);

        gboolean        (*iterParent)                   (JentchinaTreeModel* self,
                                                         JentchinaIter* out_iter,
                                                         JentchinaIter child);
};

G_BEGIN_DECLS

GType
JentchinaTreeModel_getType              (void);

/* README :
 *
 * There is no constructor since it is an abstract class
 * People using this class through the API should get a reference of such an object by using
 * a JentchinaObj like a factory
 *
 * The API is optimized for bringing an implementation of a view in GTK with minimal
 * efforts. If one had not a MVC compliant GUI toolkit used over Jentchina, we may want to use
 * the setData / getData methods in order to store for each node a reference to the "graphical node".
 * Cast any pointer to int in that case.
 * */

gint
JentchinaTreeModel_getNColumns                  (JentchinaTreeModel* self);

GType
JentchinaTreeModel_getColumnType                (JentchinaTreeModel* self,
                                                 gint index);

gboolean
JentchinaTreeModel_getIter                      (JentchinaTreeModel* self,
                                                 JentchinaIter* out_iter,
                                                 char* path);

char* /* newly allocated */
JentchinaTreeModel_getPath                      (JentchinaTreeModel* self,
                                                 JentchinaIter iter);

void
JentchinaTreeModel_getValue                     (JentchinaTreeModel* self,
                                                 JentchinaIter iter,
                                                 gint column,
                                                 GValue* out_value);

gboolean
JentchinaTreeModel_iterNext                     (JentchinaTreeModel* self,
                                                 JentchinaIter* inOut_iter);

gboolean
JentchinaTreeModel_iterChildren                 (JentchinaTreeModel* self,
                                                 JentchinaIter* out_iter,
                                                 JentchinaIter parent);

gboolean
JentchinaTreeModel_iterHasChild                 (JentchinaTreeModel* self,
                                                 JentchinaIter iter);

gint
JentchinaTreeModel_iterNChildren                (JentchinaTreeModel* self,
                                                 JentchinaIter iter);

gboolean
JentchinaTreeModel_iterNthChild                 (JentchinaTreeModel* self,
                                                 JentchinaIter* out_iter,
                                                 JentchinaIter parent,
                                                 int n);

gboolean
JentchinaTreeModel_iterParent                   (JentchinaTreeModel* self,
                                                 JentchinaIter* out_iter,
                                                 JentchinaIter child);

void
JentchinaTreeModel_print                        (JentchinaTreeModel* self,
                                                 int maxDepth,
                                                 int maxNext);

G_END_DECLS

#endif /* __JENTCHINA_TREE_MODEL_H__ */
